Savox - SW1212SG Waterproof Coreless Digital Servo - High Voltage (Waterproof)

SKU: SAVSW1212SG

$148.99

Savox - SW1212SG Waterproof Coreless Digital Servo - High Voltage (Waterproof)

SKU: SAVSW1212SG

$148.99
4 payments of $37.25 with afterpay
Or Buy Now Pay Later
Have a Question
In stock at offsite warehouse, will usually dispatch within 2-5 business days.
Description

Savox
High Torque Coreless High Voltage Digital Servo (Waterproof)
SW1212SG

This waterproof, steel-geared servo is perfect for Monster Truck and most Scaler and Crawler applications where a slightly taller servo can be fitted. Precision steel gears, stump-pulling torque, and waterproof to IP67 standards (operates for up to 30 minutes in water up to 3 feet deep).

Features:

  • Center aluminum with nylon composite top and bottom case
  • Operates directly on 7.4v without the need for an eternal BEC
  • Precision ball bearings

Specs:

  • Torque @6.0V - 36.0 kg/500 oz-in
  • Torque @7.4v - 46.0 kg/638 oz-in
  • Speed @6.0V - 0.17 sec/60 deg
  • Speed @7.4v - 0.14 sec/60 deg
  • Weight: 83g / 3.27oz
  • Dimensions L x W x H mm: 40.6 x 20.7 x 46.1

Technical Details:

  • Operating Temperature: 14° - 122°F (-10° - 50°C)
  • Running Current (no load): 120mA @6.0V, 150mA @7.4V
  • Stall Current (at locked): 8200mA @6.0V, 10000mA @7.4V
  • Idle Current: 5mA @6.0V, 5mA @7.4V
  • Wire Length: 400 +/- 5mm
  • Output Gear Spline: 25 Tooth
  • Bearings: 2BB
  • Operating Travel: 100° (1000 → 2000 µ second)
  • Neutral Position: 1500 µ second
  • Pulse Width Range: 800 → 2200 µ second
  • Maximum Travel: Appx 130° (900 → 2100 µ second)
  • Refresh Rate: 333 Hz
  • Motor Type: Coreless
